SUPERBOX 6 HD
Robopac presents an automatic carton forming machine with a high output and a long lifespan. The new Superbox forming machine retrieves the cardboard blanks, opens, folds and forms the boxes and then seals the bottom with tape.

The SUPERBOX 6 HD is a high-capacity, heavy-duty strapping machine designed for fast, efficient, and reliable bundling of cartons and palletized loads. Engineered for industrial-scale operations, it combines robust construction with advanced automation to ensure consistent performance in demanding production environments.
Equipped with a powerful tensioning and sealing system, the SUPERBOX 6 HD guarantees secure strapping while optimizing material usage, reducing waste, and increasing productivity. Its intuitive control panel allows operators to easily adjust strap tension, cycle speed, and program multiple strapping cycles for different load types.
Key features include:
- High-speed strapping cycles for maximum throughput
- Heavy-duty frame and components for long-term industrial use
- Adjustable tension control for different load requirements
- User-friendly interface for easy operation and program customization
- Optimized strap application to minimize material waste and improve load stability
- Integrated safety systems to protect operators during operation
Ideal for warehouses, logistics centers, and manufacturing plants, the SUPERBOX 6 HD provides efficient, reliable, and cost-effective strapping, improving operational efficiency and ensuring consistent load security.
Specification
| Box storage capacity | 50-60 std. 100-120 opt. | |
| Height conveyor belt | mm | 50 |
| Infeed speed | m/min | 22 |
| Tape width | mm | 50 – 75 |
| Bottom taping head | opt | |
| Minimum boxes dimensions (LxWxH) | mm | 200x170x100 |
| Maximum boxes dimensions (LxWxH) | mm | 600x410x500 |
| Max box weight | kg | 50 |
| Power supply voltage | V | 400 V 3 Ph + N + PE |
| Power supply frequency | Hz | 50 |
| Installed power | kW | 0,6 (0,8 with motorized storage unit) |
| Air consumption | Nl/min | 350 |
| Working pressure | bar | 5 |
